SOW 6160
SOW 6160
SOW 6160
SOW 6160
SOW 6160
SOW 6160

SOW 6160

wall mount speaker

The SOW 6160 is a passive 2-way wall-mount speaker featuring a 6-inch low-frequency driver and a 1-inch dome tweeter. It includes a dedicated pan-and-tilt wall-mounting bracket for flexible horizontal and vertical positioning.

Warranty

2 Years

Dimensions

181mm×200mm×303mm

  • 2-way speaker with 6-inch LF driver and 1-inch HF driver

  • Compact and sturdy enclosure

  • Balanced frequency response for warmth, detail and clarity

  • Direct 8-ohm and 100V/70V inputs with multiple power taps

  • Weatherised IP65 construction for outdoor use

  • Powder-coated aluminium grille

  • Powder-coated aluminium mounting bracket

  • Horizontal and vertical tilt adjustment

  • Available in white and black

DESCRIPTION
Wall mount speaker
SYSTEM
Passive 2 way bass reflex
TRANSDUCER COMPLEMENTS
HF 1 x 1" dome tweeter, LF 1 x 6" woofer
FREQUENCY RESPONSE
60Hz ~ 20kHz, ± 6dB
POWER HANDLING DIRECT MODE
80W
POWER TAPS, 100V
7.5W, 15W, 30W, 60W
POWER TAPS, 70V
3.75W, 7.5W, 15W, 30W
NOMINAL IMPEDANCE
8Ω
SENSITIVITY (1W 1M)
90dB (half space)
MAX SPL DIRECT MODE
109dB
INPUT
Push type terminal, colour coded
IP RATING
IP65
GRILL
Aluminium mesh powder coated
ENCLOSURE
Polypropylene
COLOURS
White/ Black
DIMENSIONS (WxHxD)
200mm x 303mm x 181mm
NET WEIGHT
2.8kg
MOUNTING OPTIONS
Pan and tilt wall-mounting bracket

NOTE: Due to continuous improvements, all specifications are subject to change
