2 way passive speaker for indoor and outdoor usage

SPA 1312 is a two way passive speaker with 12” LF and throat compression driver which can be used indoors and outdoors; detailed specifications are given below

Warranty

2 Years

Dimensions

415mm × 410mm ×682mm

  • High performance 2 way speaker with 12" woofer, 1.75" HF compression driver

  • Smooth, wide frequency response

  • With direct and LMT inputs. ideal for installation, indoor and outdoors

  • Rigid PP enclosure fitted with handles for lifting

  • Can be flown - 6 inserts provided for same

  • Wedge type shape allows use as stage monitor

  • Integrated pole mount for stands and brackets

  • Weatherised to meet IP 44 standards

DESCRIPTION
Passive 2 way speaker system, weatherised
TRANSDUCER COMPLEMENTS
HF: 1 x 1" throat compression driver, 1.75" VC LF: 1 x 12" woofer, 2.5" VC
ENCLOSURE MATERIAL
Industrial grade PP, Black
FORM FACTOR
Trapezoidal, can be used as stage monitor
ACOUSTIC FREQUENCY RANGE
50Hz ~ 18kHz
ACOUSTIC FREQUENCY RESPONSE
60Hz ~ 17kHz
MAX SPL AT HALF SPACE
Continuous: 122dB; Peak: 128dB
DIRECTIVITY (HxV)
90° x 50°
OUTPUT POWER
Continuous: 400W Program: 800W Peak: 1600W
CROSSOVER FREQUENCY
1.5kHz
POWER TAPS, 100V
300W, 150W, 75W, 37.5W
POWER TAPS, 70V
150W, 75W, 37.5W, 18.8W
INPUT
Twist- lock connector
IP RATING
IP44
MOUNTING OPTIONS
3 x M8 inserts on top, 2 x M8 inserts on bottom and 1 x M8 insert at back, for flying; Twin 35 mm pole mounting; 4 x plastic legs
COLOURS
Black
DIMENSIONS (WxHxD)
360mm x 610mm x 350mm
NET WEIGHT
15.2kg

NOTE: Due to continuous improvements, all specifications are subject to change
