SPA 1308
SPA 1308
SPA 1308
SPA 1308
SPA 1308
SPA 1308
SPA 1308
SPA 1308

SPA 1308

2 way passive speaker for indoor and outdoor usage

SPA 1308 is a 2 way passive speaker with 8” LF and throat compression driver which can be used indoors and outdoors; detailed specifications are given below

Warranty

2 Years

Dimensions

326mm ×326mm×490mm

  • High performance 2 way speaker with 8" woofer, 1.35" HF compression driver

  • Smooth, wide frequency response

  • With direct and LMT inputs. ideal for installation, indoor and outdoors

  • Rigid PP enclosure fitted with handles for lifting

  • Can be flown - 6 inserts provided for same

  • Wedge type shape allows use as stage monitor

  • Integrated pole mount for stands and brackets

  • Weatherised to meet IP 44 standards

DESCRIPTION
Passive 2 way speaker system, weatherised
TRANSDUCER COMPLEMENTS
HF: 1 x 1" throat compression driver, 1.35" VC; LF: 1 x 8" woofer, 1.5" VC
ENCLOSURE MATERIAL
Industrial grade PP, Black
FORM FACTOR
Trapezoidal, can be used as stage monitor
ACOUSTIC FREQUENCY RANGE
60Hz ~ 18kHz
ACOUSTIC FREQUENCY RESPONSE
70Hz ~ 17kHz
MAX SPL AT HALF SPACE
Continuous: 117dB; Peak: 123dB
DIRECTIVITY (HxV)
90° x 50°
OUTPUT POWER
Continuous: 200W Program: 400W Peak: 800W
CROSSOVER FREQUENCY
2.5kHz
POWER TAPS, 100V
80W, 40W, 20W,10W
POWER TAPS, 70V
40W, 20W, 10W, 5W
INPUT
Twist- lock connector
IP RATING
IP44
PROTECTION
Overload, Short-circuit, Overheat, Mains Overvoltage
MOUNTING OPTIONS
2 x M8 inserts 3 x M8 inserts on top,2 x M8 inserts on bottom and 1 x M8 insert at back, for flying Twin 35 mm pole mounting 4 x plastic legson top, 2 x M8 inserts on bottom and 1 x M8 insert at back, for flying; Twin 35 mm pole mounting; 4 x plastic legs
COLOURS
Black
DIMENSIONS (WxHxD)
250mm x 420mm x 255mm
NET WEIGHT
9.6kg

NOTE: Due to continuous improvements, all specifications are subject to change
