SH30
Horn, 30W, IP66 Rated
The Australian Monitor SH30 horn is both constant voltage and low impedance, designed for paging and background music systems requiring vocal clarity and sound projection.
Warranty
2 Years
Diameter
249mm
30 watts power rating RMS
Power taps 30, 15, 7.5, 3.8W and 8 ohm
Frequency response 350Hz-9.5kHz
111dB sensitivity (1W/1M)
Aluminium flare and ABS housing
Includes capacitor for EVAC purposes
2.0kg
DESCRIPTION
Horn Speaker
TRANSDUCER COMPLEMENTS
40mm driver diameter
FREQUENCY RESPONSE
350Hz ~ 9.5kHz (-3dB)
MAX POWER
CONTINUOUS 30W, PROGRAM 60W, PEAK 120W
SPL, 1W 1M
111dB
MAX SPL
RMS 126dB, PEAK 132dB
POWER TAPS
30W, 15W, 5W, 7.5W, 3.75W, 1.87W - 8Ω
IP RATING
IP66
COLOURS
White
DIMENSIONS (WxHxD)
249mm x 300m x 280mm
NET WEIGHT
2kg
NOTE: Due to continuous improvements, all specifications are subject to change
