SLX 1252
3 way passive speaker
SLX 1252 is a three way passive speaker with dual 15” LF and horn loaded compression driver; detailed specifications are given below
Warranty
2 Years
Dimensions
517mm×560mm×1416mm
Portable and fixed install PA speakers
High power handling and SPL
Constant directivity HF with custom waveguide
Rigid painted cabinet with heavy internal bracing
High excursion LF transducer
DESCRIPTION
Passive 3 way, dual 15", bass-reflex
ENCLOSURE TYPE
15mm plywood, Trapezoidal
TRANSDUCER COMPLEMENTS
HF: 1" HLCD with 2" VC, LF: 2 x 15" with 3" VC
NOMINAL IMPEDANCE
4Ω
FREQUENCY RANGE
35Hz ~ 20kHz (-10dB)
DIRECTIVITY (HxV)
90° x 50° HF
SENSITIVITY (1W 1M)
100dB
MAX SPL
CONTINUOUS: 132dB, PEAK: 138dB
POWER HANDLING
CONTINUOUS: 1500W, PROGRAM: 300W, PEAK: 6000W
CONNECTORS
1 x Twist-lock connector (input) 1 x Twist-lock connector (link)
FINISH
Durable paint
MOUNTING OPTIONS
Stackable
DIMENSIONS (WxHxD)
560mm x 1416mm x 517mm
NET WEIGHT
68kg
NOTE: Due to continuous improvements, all specifications are subject to change
- Product LiteratureDownload
